Writing a preemptive task scheduler for AVR

Wow it has been a while. Between school, work, and another project that I’ve been working on since last October (which, if ultimately successful, I will post here) I haven’t had a lot of time to write about anything cool.

I wanted to share today something cool I wrote for my AVRs. Many of my recent AVR projects have become rather complex in that they usually are split into multiple parts in the software which interact with each other. One project in particular had the following components:

  • A state machine managing several PWM channels. It implemented behavior like pulsing, flashing, etc. It also provided methods for the other components to interact with it.
  • A state machine managing an NRF24L01+ radio module, again providing methods for components to interact with it.
  • A state machine managing several inputs, interpreting them and sending commands to the other two components

So, why did I use state machines rather than just implementing this whole thing in a giant loop with some interrupts mixed in? The answer is twofold:

  1. Spaghetti. Doing things in state machines avoided spaghetti code that would have otherwise made the system very difficult to modify. Each machine was isolated from the others both structurally and in software (static variables/methods, etc). The only way to interact with the state machines was to use my provided methods which lends itself to a clean interface between the different components of the program. Switching out the logic in one part of the program did not have any effect on the other components (unless method signatures were changed, of course).
  2. Speed. All of these state machines had a requirement of being able to respond quickly to events, whether they were input events from the user or an interrupt from a timer and whatnot. Interrupts make responding to things in a timely fashion easy, but they stop all other interrupts while running (unless doing nested interrupts, which is …unwieldy… in an AVR) and so doing a lot of computation during an interrupt can slow down the other parts of the system. By organizing this into state machines, I could split up parts of computation into pieces that could execute fast and allow other parts to run in response to their interrupts quickly.

None of this, however, is particularly new. Everyone does state machines and they are comparatively easy to implement. In almost every project I have done there has been some form of state machine, whether it was just busy waiting for some flag somewhere and doing something after that flag was set, or doing something much more complex. What I wanted to show today was a different way of dealing with the issues of spaghetti and speed: Building a preempting task scheduler. These are considered a key and central component of Real-Time Operating Systems, so what you see in this article is the beginnings of a real-time kernel for an AVR microcontroller.

I should mention here that there is a certain level of ability assumed with AVRs in this post. I assume that the reader has a good knowledge of how programs work with the stack, the purpose and functioning of the general purpose registers, how function calls actually happen on the microcontroller, how interrupts work, the ability to read AVR assembly (don’t worry most of this is in C…but there is some critical code written in assembly), and a general knowledge of the avr-gcc toolchain.

Table of Contents

Preemption?

The definition of preemption in computing is being able to interrupt a task, without its cooperation, with the intention of executing it later, in order to run some other task.

Firstly we need to define a task: A task is a unit of execution; something that the program structure defines as a self-contained part of the program which accomplishes some purpose. In our case, a task is basically going to just be a method which never returns. The next thing to define is a scheduler. A scheduler is a software component which can decide from a list of tasks which task needs to run on the processor. The scheduler uses a dispatcher to actually change the code that is executing from the current task to another one. This is called saving and restoring the context of the task.

The cool thing about preemptive scheduling is that any task can be interrupted at any time and another task can start executing. Now, it could be asked, “Well, isn’t that what interrupts do? What’s the difference?”. The difference is that an interrupt in a system using a preemptive scheduler can actually resume in a different place from when it started. Without a scheduler, when an interrupt ends the processor will send the code right back to where it was executing when the interrupt occurred. In contrast, the scheduler actually allows the program to have a little more control and move from one task to another in response to an interrupt or some other stimuli (yes, it doesn’t even need to be an interrupt…it could be another task!).

In the state machine example above, I used state machines as a way to break up computations so that the other machines could run at predetermined points. I noticed that in most of these cases, this point was when waiting for some user input or an interrupt. Although I used interrupts extensively in the application, there were a lot of flags to be polled and this happened inside state machine tick functions. When an interrupt occurred and set a flag, it would need to wait for the “main” code to get around to executing the tick function for the particular state machine that listens to the flag before anything could happen. This introduces a lot of latency and jitter (differences in the amount of time it takes the system to respond to an interrupt from one moment to the next). Not good.

Using tasks removes a lot of these latency problems since the interrupt can halt the current task (block) and begin executing another which was waiting on the interrupt to occur (unblock or resume). Once the higher priority task is blocked again (through a call to some function asking it to wait for some event), the scheduler will change back to the original task and things go on as usual. Using tasks also has the effect of making the code easier to read. While state machines are easy to write, they are not always easy to follow. A function is invoked over and over again and that requires more thought than simply reading a linear function. Tasks can be very linear since the state machine is embodied in calls which could possibly block the task.

A positive side effect of doing things this way (with a scheduler) is that we can now implement the familiar things such as semaphores and queues to communicate between our tasks in a fine grained manner. At their core these are simply methods that can manipulate the list of tasks and call the scheduler to decide which task to execute next.

Summary: Using a preemptive scheduler can allow for lower latency and jitter between an interrupt occurring and some non-ISR code responding to it when compared to using several state machines. This means it will respond more consistently to interrupts occurring, though not necessarily in a more timely fashion. It also allows for fine-grained priority control with these responses.

Pros and Cons

Before continuing, I would like to point out some pros and cons that I see of writing a task scheduler lest we fall into the “golden hammer” antipattern. There are certainly more, but here is my list (feel free to comment with comments on this).

Some Pros

  • Can reduce the jitter (and possibly the latency) in responding to interrupts. This is of paramount importance in some embedded systems which will have problems if the system cannot respond in a predictable manner to external stimuli.
  • Can greatly simplify application code by using familiar constructs such as semaphores and queues. Compared to state machines, this code can be easier to read as it can be written very linearly (no switches, if’s etc). This can reduce the initial bugs found in programs.
  • Can entirely remove the need for busy waits (loops polling a flag). A properly designed state machine shouldn’t have these either, but it can take a large amount of effort to design these kinds of machines. They also can take up a lot of program space when space is at a premium (not always true).
  • Can reduce application code size. This is weak, but since the code can be made more linear with calls to the scheduler rather than returning all the time, there is no need for switch statements and ifs which can compile to some beastly assembly code.

Some Cons

  • Can add unnecessary complexity to the program in general. A task scheduler is no small thing and brings with it all of the issues seen in concurrent programming in general. However, these issues usually already exist when using interrupts and such.
  • Can be very hard to debug. I needed an emulator to get this code working correctly. Anything where we mess with the stack pointer or program counter is going to be a very precise exercise.
  • Can make the application itself hard to debug. Is it a problem with the scheduler? Or is it a problem with the program itself? It is an additional component to consider when debugging.
  • Adds additional program weight. My base implementation uses ~450 bytes of program memory. While quite tiny compared to many programs, this would be unacceptably high on a smaller AVR such as the ATTiny13A which only has 1K of program memory.

So…lots of those are contradictory. What is a pro can also be a con. Anyway, I’m just presenting this as something cool to do, not as the end all be all of ways to structure an embedded program. If you have a microcontroller that is performing a lot of tasks that need to be able to react reliably to an interrupt, this might be the way to go for you. However, if your microcontroller is just toggling some gpios and reacting to some timers, this might be overkill. It all depends on the application.

Implementation

Mmmkay here’s the fun part. At this point you may be asking, “How in the world can we make something that can interrupt during one function and resume into another?” I recently completed a course on Real-Time Operating Systems (RTOS) at my university which opened my eyes into how this can be done (we wrote one for the 8086…so awesome!), so I promptly wrote one for the AVR. For those who come by here who have taken the same course at BYU, they will notice some distinct similarities since I went with what I knew. I’ve named it KOS, for “Kevin’s Operating System”, but this was just so I had an easy prefix for my types and function names. If you’re going to implement your own based on this article, don’t worry about naming it like mine (though a mention of this article somewhere would be cool).

Disclaimer: I have only started to scratch the surface of this stuff myself and I may have made some errors. I appreciate any insight anyone can give me into either suggestions for this or problems with my implementation. Just leave it in the comments :)

All of the code can be found here: https://github.com/kcuzner/kos-avr

The focus of a scheduler/dispatcher system for tasks is manipulating the stack pointer and the stack itself. “Traditionally,” programs written for microcontrollers have a single stack which grows from the bottom of memory up and all code is executed on that stack. The concept here is that we still start out with that stack, but we actually execute the tasks on their own separate stacks. When we want to switch to a task, we point the AVR’s stack pointer to the desired task’s stack and start executing (its the “start executing” part where things get fun).

First, let’s take a look at the structure which represents a task:

The very first item in this struct is the pointer to the stack pointer (*sp). It is a void* because we don’t normally access anything on it…we just make the SP register point to it when we want to execute the task.

The next item in the struct is a status enum. This is used by my primitive scheduler to determine if a task is “READY” to execute. If a task is ready to execute, then it is not waiting on anything (i.e. blocked) and it can be resumed at any time. In the case where the task is waiting on something like a semaphore, this status would be changed to SEMAPHORE. The semaphore posting code would then change the status back to READY once somebody posted to the semaphore. This is called “unblocking”.

After the status comes the *next pointer. The tasks are arranged in a linked list because they have a priority attached to them. This priority determines which tasks get executed first. At the top of the linked list is the highest priority task and at the end of the list is the lowest priority task.

Finally, we have the *status_pointer. This is used by our functions which can unblock tasks to determine why tasks are blocked in the first place. We will see more about this when we make a primitive semaphore.

Ok, so for the basic task scheduling and dispatching functionality we are going to implement some functions (these are declared in a header):

As for source files, we will only have a single C file for the implementation, but there will be some inline assembly because we are going to have to fiddle with registers. Yay! I’ll just go through the functions one by one and afterwards I’ll go through my design decisions and how they affect things. This is not the only, nor the best, way to do this.

Implementation: kos_init and kos_new_task

Firstly, we have the kos_init and kos_new_task functions, which come with some baggage:

Here we have two concepts that are embodied. The first is the context. The context the data pushed onto the stack that the dispatcher is going to use in order to restore the task before executing it. This is similar (identical even) to the procedure used with interrupt service routines, except that we store every single one of the 32 registers instead of just the ones that we use. The next concept is that of the idle task. As an optimization, there is a task which has the lowest priority and is never blocked. It is always ready to execute, so when all other tasks are blocked, it will run. This means that we don’t have to deal with the case in the scheduler when there is no tasks to execute since there will always be a task.

The kos_init function performs only one operation: Add the idle task to the list of tasks to execute. Notice that there was some space allocated for the stack of the idle task. This stack must be at least as large as the entire context (35 bytes here) plus enough for any interrupts which may occur during program execute. I chose 48 bytes, but it could be as large as you want. Also take note of the pointer that we pass for the stack into kos_new_task: It is a pointer to the end of our array. This is because stacks grow “up” in memory, meaning a push decrements the address and a pop increments it. If we passed the beginning of the array, the first push would make us point before the memory allocated to the stack since arrays are allocated “downwards” in memory.

The kos_new_task function is a little more complex. It performs two operations: setting up the initial context for the function and adding the Task structure to the linked list of tasks. The context needs to be set up initially because from the scheduler’s perspective, the new task is simply an unblocked task that was blocked before. Therefore, it expects that some context is stored on that task’s stack. Our context is ordered such that the PC (program counter) is first, the 32 registers are next, and the status register is last. Since the stack is last-in first-out, the SREG is popped first, then the 32 registers, and then the PC. We can see at the beginning of the function that we take the function pointer (they are usually 16 bits on most AVRs…the ones with lots of flash do it differently, so consult your datasheets) and set it up to be the program counter. It is arranged LSB-first, so the LSByte is “pushed” before the MSByte. The order here is very important and the reason why will become very apparent when we see the code for the dispatcher. After that, we put 32 0’s onto the stack. These are the initial values for the registers and 0 seemed like a sensible value. The very last byte “pushed” is the status register. We set it to 0x80 so that the interrupt flag is set. This is a design decision to prevent problems with forgetting to enable interrupts for every task and having one task where we forgot to enable it prevent all interrupts from executing. Finally, the top of the stack (note the subtraction of 35 bytes from the stack pointer) is stored on the Task struct along with the initial task state. We add it to the task list as the head of the list, so the last task added is the task with the highest priority.

Implementation: kos_run and kos_schedule

Next we have the kos_run function:

Well that’s simple: it just calls the scheduler. So, let’s look at kos_schedule:

The very first thing to notice is the kos_isr_level reference. This solves a very specific problem that occurs with ISRs which I talk about in the next section. Other than that bit, however, this is also simple. Because our tasks in the linked list are ordered by priority, we can simply start at the top and move along the linked list until we locate the first task that is ready (unblocked). Once that task is found, we will call the dispatcher if the task we found is not the currently executing task.

The purpose of the ATOMIC_BLOCK is to ensure that interrupts are disabled when the dispatcher runs. Since the stack is going to be manipulated, the entire dispatcher is considered to be a critical section of code and must be run atomically. The ATOMIC_BLOCK will restore the interrupt status after kos_dispatch returns (which is after the task has been resumed).

Implementation: kos_enter_isr and kos_exit_isr

We are faced with a very particular problem when we want to call our scheduler inside of an interrupt. Let’s imagine a scenario where we have two tasks, Task A and Task B (Task A has higher priority than Task B), in addition to the idle task. Task A uses waits on two semaphores (semaphores 1 and 2) that is signaled by an ISR. When task A is running, it signals another semaphore that Task B waits on (semaphore 3). Here is what happens:

  1. The idle task is running because both Task A and Task B are waiting on semaphores.
  2. An interrupt occurs (note that it happens during the idle task) and the ISR begins executing immediately. An ISR can be thought of as a super high priority task since it will interrupt anything.
  3. The ISR posts to semaphore 1 which Task A is waiting on. The very next statement is going to be to signal semaphore 2 as well. However, this happens next:
  4. After signaling semaphore 1, the dispatcher runs and Task A begins to execute. Task A signals semaphore 3 which will cause Task B to run. Since Task A has a higher priority than B, however, Task B isn’t executed yet. Task A goes on to wait on semaphore 2. This then causes Task B to be dispatched.
  5. Task B takes a really long time to run, but it finally ends. There are no more tasks on the ready list, so the idle task begins to run.
  6. The idle task resumes inside the ISR and posts to semaphore 2.
  7. Task A begins running again.

As straightforward as that may seem, that isn’t the intended behavior. Imagine if a task with an even higher priority than A had the ISR occur while it was executing. The sequence above would be totally different because Task A wouldn’t be dispatched after the 1st semaphore being posted (item #4). Let’s see what happens:

  1. The idle task is running because both Task A and Task B are waiting on semaphores.
  2. An interrupt occurs (note that it happens during the idle task) and the ISR begins executing immediately. An ISR can be thought of as a super high priority task since it will interrupt anything.
  3. The ISR posts to semaphore 1 which task A is waiting on.
  4. After signaling semaphore 1, the scheduler notices that the current task has a higher priority than Task A, so it does not dispatch.
  5. The ISR posts to semaphore 2.
  6. Same as #4. The ISR ends. Let’s say that the high priority task blocks soon afterwards.
  7. Once the high priority task has blocked, Task A is executed. It posts to semaphore 3 and then waits on semaphore 2. Since semaphore 2 has already been posted, it continues right on through without a task switch to Task B. This is a major difference in the order of operations.
  8. After Task A finally blocks, Task B executes.

Because of the inconsistency and the fact that the ISR “priority” when viewed by the scheduler is determined by possibly random ISRs (making it non-deterministic), we need fix this. The solution I went with was to make two methods: kos_enter_isr and kos_exit_isr. These should be called when an ISR begins and when an ISR ends to temporarily hold off calling the scheduler until the very end of the ISR. This has the effect of giving an ISR an apparently high priority since it will not switch to another task until it has completely finished. So, although the idle task may be running when the ISR occurs, while the ISR is running no context switches will occur until the very end. Here is some code:

As seen in kos_schedule, we use the kos_isr_level variable to indicate to the scheduler whether we are in an ISR or not. When kos_isr_level finally returns to 0, the scheduler will actually perform scheduling when it is called at the end of kos_isr_exit. The second set of events described earlier will now happen every time, even if the idle task is interrupted.

These functions must be run with interrupts disabled since they don’t use any sort of locking, but they should support nested interrupts so long as they are called at the point in the interrupt when interrupts have been disabled.

Implementation: kos_dispatch

The dispatcher is written basically entirely in inline assembly because it does the actual stack manipulation:

So, a lot is happening here. There are 4 basic steps: Save the current context, update the current task’s stack pointer, change the stack pointer to the next task, and restore the next task’s context.

Inline assembly has an interesting syntax in GCC. I don’t believe it is fully portable into non-GCC compilers, so this makes the code depend more or less on GCC. Inline assembly works by way of placeholders (called Operands in the manual). At the very end of the assembly statement, we see a series of comma-separated statements which define these placeholders/operands and how the assembly is going to use registers and such. First off, we pass in the SREG, SPL, and SPH registers as type “i”, which is a constant number known at compile-time. These are simply the IO addresses for these registers (found in avr/io.h if you follow the #include chain deep enough). The next couple parameters are also “i” and are simply bit numbers and masks. The last parameter is the next task pointer passed in as an argument. This is the part where we see the reason why it is more convenient to do this in inline assembly rather than writing it up in an assembly file. While it is possible to look up how avr-gcc passes arguments to functions and discover that the arguments are stored in a certain order in certain registers, it is far simpler and less breakable to allow gcc to fill in the blanks for us. By stating that the _next_task_ placeholder is of type “r” (register), we force GCC to place that variable into some registers of its choosing. Now, if we were using some global variable or a static local, gcc would generate some code before our asm block placing those values into some registers. For this application, that could be quite bad since we depend on no (possibly stack-manipulating) code appearing between the function label and our asm block (more on this in the next paragraph). However, since arguments are passed by way of register, gcc will simply give us the registers by which they are passed in to the function. Since pointers are usually 16 bits on an 8-bit AVR (larger ones will have 3 bytes maybe…but I’m really not sure about this), it fits into two registers. We reference these in the inline assembly by way of “%A[_next_task_]” and “%B[_next_task_]” (note the A and B…these denote the LSB and MSB registers).

Storing the context is pretty straightforward: push all of the registers and push the status register. At this point you may ask, “What about the program counter? Didn’t we have to push that earlier during kos_new_task?” When the function was called (using the CALL instruction), the return address was pushed onto the stack as a side-effect of that instruction. So, we don’t need to push the program counter because it is already on there. This is also why it would be very bad if some code appeared before our asm block. It is likely that gcc will clear out some space on the stack and so we would end up with some junk between the return address on the stack and our first “push” instruction. This would mess up the task context frame and we will see later in the code that this will prevent this function from dispatching the task correctly when it became time for the task to be resumed.

Updating the stack pointer is slightly more tricky. Interrupts are disabled first because it would really suck if we got interrupt during this part (anytime the stack pointer is manipulated is a critical section). We then get to dereference the kos_current_task variable which contains our current task. If we remember from above, the very first thing in the KOS_Task structure is the stack pointer, so if we dereference kos_current_task, we are left with the address at which to store the stack pointer. From there, its as simple as loading the stack pointer into some registers and saving it into Indirect Register X (set by registers 26 and 27).

I should note here something about clearing the interrupt flag. Normally, we would want to check to see if interrupts were enabled beforehand so that we can know if we need to restore them. This code lacks an explicit check because of the fact that the status register (with interrupts possibly enabled) has already been stored. Later, when the current task is restored, the SREG will be restored and thus interrupts will be turned back on if they need to be. Similarly, if the next task has interrupts enabled, they will turned on in the same fashion.

After updating kos_current_task’s stack pointer, we get to move the stack to the next task and set kos_current_task to point to the next task. This is essentially the reverse of the previous operation. Instead of writing to Indirect Register X (which points to the stack pointer of the task), we get to read from it. We also slip in a couple instructions to update the kos_current_task pointer so that it points to the next task. After we have changed the SPL and SPH registers to point to our new stack, the task passed into kos_dispatch is ready to be resumed.

Resuming the next task’s context is a little less straightforward than saving it. We need to ensure that in the case that the global interrupt flag is going to be set in the status register that it isn’t set until the end of the whole routine since this should thing needs to be atomic to reduce the largest possible stack size. This is done by transferring the interrupt flag in the status register into the T (transfer) bit in the status register (that’s the “bst” and “bld” instructions), clearing the interrupt flag, and then later executing either the ret or reti instruction based on this flag. The side effect is that we trash the T bit. I am not sure I can actually do this. This is one part that is tricky: The avr-gcc manual states that the T flag is a scratchpad, just like r0, and doesn’t need to be restored by called functions. My logic here is that since the only way for a task to become blocked is either it being executed initially or from a call to kos_dispatch, gcc sees the dispatch call as a normal function call and will not assume that the T flag will remain unchanged.

After dancing around with bits and restoring the modified SREG, we proceed to pop off the rest of the registers in the reverse order that they were stored at the beginning of the function. At the very end, we use a T flag branch instruction to determine which return instruction to use. “ret” will return normally without setting the interrupt flag and “reti” will set the interrupt flag.

Implementation: Results by code size

So, at this point we have implemented a task scheduler and dispatcher. Here is how it weighs in with avr-size when compiled for an ATMega48A running just the idle task:

Not the best, but its reasonable. The data usage could be taken down by reducing the number of maximum tasks. There are other RTOS available for AVR which can compile smaller. We could do several optimizations which I will discuss in the conclusion

Example: A semaphore

So, we now have a task scheduler. The thing is, although capable of running multiple tasks, it is not possible for multiple tasks to actually run. Why? Because kos_dispatch is never called! We need something that causes the task to become blocked.

As a demonstration, I’m going to implement a simple semaphore. I won’t go into huge detail since that isn’t the point of this article (and it has been long enough), but here is the code:

Header contents:

Source contents:

So, our semaphore will cause a task to become blocked when kos_semaphore_pend is called (and the semaphore value was <= 0) and when kos_semaphore_post is called, the highest priority task that is blocked on the particular semaphore will be made ready.

Just so this makes sense, let’s go through an example sequence of events:

  1. Task A is created. There are now two tasks on the task list: Task A and the idle task.
  2. Semaphore is initialized to 1 with kos_semaphore_init(1);
  3. Task A calls kos_semaphore_pend on the semaphore. The value is decremented, but it was >0 before the decrement, so the pend immediately returns.
  4. Task A calls kos_semaphore_pend again. This time, the kos_current_task (which points to Task A) state is set to blocked and the blocking data points to the semaphore. The scheduler is called and since Task A is now blocked, the idle task will be dispatched by kos_dispatch.
  5. The idle task runs and runs
  6. Eventually, some interrupt could occur (like a timer or something). During the course of the ISR, kos_semaphore_post is called on the semaphore. Every call to kos_semaphore_post allows exactly one task to be resumed, so it goes through the list looking for the highest priority task which is blocked on the semaphore. Task A is resumed at the point immediately after the call to kos_dispatch in kos_schedule. kos_schedule returns after a couple instructions restoring the interrupt flag state and now Task A will run until it is blocked.

Here’s a program that does just this:

Running this with avr-gdb and simavr we can see this in action. I placed breakpoints at the val++ line and the kos_semaphore_post line. Here’s the output with me pressing Ctrl-C at the end once it got into and stayed in the infinite loop in the idle task:

You may have noticed that the interrupt was called three times before we even got to val++. The reason for this is that timer0 is an 8-bit timer and I used no prescaler for its clock, so the interrupt will happen every 255 cycles. Given that the dispatcher is nearly 100 instructions and the scheduler isn’t exactly short either, the interrupt could easily be called three times before it manages to resume the task after it blocks (including the time it takes to block it).

A word on debugging

Before I finish up I want to mention a few things about debugging with avr-gdb. This project was the first time I had ever needed to use an simulator and debugger to even get the program to run. It would have been impossible to write this using an actual device since very little is revealed when operating the device. Here are a few things I learned:

  • avr-gdb is not perfect. For example, it is confused by the huge number of push statements at the beginning of kos_dispatch and will crash if stepped into that function (if it receives a break inside kos_dispatch that seems to work sometimes). This is due to avr-gdb attempting to decode the stack and finding that the frame size of the function is too big. It’s weird and I didn’t quite understand why that limitation was there, so I didn’t really muck around with it. This made debugging the dispatcher super difficult.
  • Stack bugs are hard to find. I would recommend placing a watch on the top of your stack (the place where the variable actually points) and then setting that value to something unlikely like 0xAA. If you see this value modified, you know that there is a problem since you are about to exceed your stack size. I spent hours staring at a problem with that semaphore example above before I realized that the idle task stack had encroached on the semaphore variables. Even then, I was looking at something totally different and just noticed that the stack pointer was too small. As it turns out, my original stack size of 48 was too small. The dispatcher will always require at least 35 free bytes on the stack and any ISR that calls a function will require at least 17 bytes due to the way that functions are called in avr-gcc. 35+17 = 52 which is greater than 48…so yeah. Not good.
  • Simavr is pretty good. It supports compiling a program that embeds simavr which can be used to emulate the hardware around the microcontroller rather than just the microcontroller itself. I didn’t use this functionality for this project, but that is a seriously cool thing.

Conclusion

This has been a long post, but it is a complicated topic. Writing something like this is actually considered writing an operating system (albeit just the kernel portion and a small one at that) and the debug along for just this post took me a while. One must have a good knowledge of how exactly the processor works. I found my knowledge lacking, actually, and I learned a lot about how the AVR works. The other thing is that things like concurrency and interrupts must be considered from the very beginning. They can’t be an afterthought.

The scheduler and dispatcher I have described here are not perfect nor are they the most optimal efficient design. For one thing, my design uses a huge amount of RAM compared to other RTOS options. My scheduler and dispatcher are also inefficient, with the scheduler having an O(N) complexity depending on the number of tasks. My structure does, however, allow for O(1) time when suspending a task (although I question the utility of this…it worked better with the 8086 scheduler I made for class than with the AVR). Another problem is that kos_dispatch will not work with avr-gdb if the program is stopped during this function (it has a hard time decoding the function prologue because of the large number of push instructions). I haven’t found a solution to this problem and it certainly made debugging a little more difficult.

So, now that I’ve told you some of what’s wrong with the above, here are two RTOS which can be used with the AVR and are well tested:

  • FemtoOS. This is an extremely tiny and highly configurable RTOS. The bare implementation needs only 270 bytes of flash and 10 bytes of RAM. Ridiculous! My only serious issue with it is that it is GPLv3 licensed and due to how the application is compiled, licensing can be troublesome unless you want to also be GPLv3.
  • FreeRTOS. Very popular RTOS that has all sorts of support for many processors (ARM, PPC, AVR…you name it). I’ve never used it myself, but it also seems to have networking support and stuff like that. The site says that it’s “market leading.”

Anyway, I hope that this article is useful and as usual, any suggestions and such can be left in the comments. As mentioned before, the code for this article can be found on github here: https://github.com/kcuzner/kos-avr

Teensy 3.1 bare metal: Writing a USB driver

One of the things that has intrigued me for the past couple years is making embedded USB devices. It’s an industry standard bus that just about any piece of computing hardware can connect with yet is complex enough that doing it yourself is a bit of a chore.

Traditionally I have used the work of others, mainly the V-USB driver for AVR, to get my devices connected. Lately I have been messing around more with the ARM processor on a Teensy 3.1 which has an integrated USB module. The last microcontrollers I used that had these were the PIC18F4550s that I used in my dot matrix project. Even with those, I used microchip’s library and drivers.

Teensy 3.1

Teensy 3.1

Over the thanksgiving break I started cobbling together some software with the intent of writing a driver for the USB module in the Teensy myself. I started originally with my bare metal stuff, but I ended up going with something closer to Karl Lunt’s solution. I configured code::blocks to use the arm-none-eabi compiler that I had installed and created a code blocks project for my code and used that to build it (with a post-compile event translating the generated elf file into a hex file).

This is a work in progress and the git repository will be updated as things progress since it’s not a dedicated demonstration of the USB driver.

The github repository here will be eventually turned in to a really really rudimentary 500-800ksps oscilloscope.

The code: https://github.com/kcuzner/teensy-oscilloscope

The code for this post was taken from the following commit:

https://github.com/kcuzner/teensy-oscilloscope/tree/9a5a4c9108717cfec0174709a72edeab93fcf2b8

At the end of this post, I will have outlined all of the pieces needed to have a simple USB device setup that responds with a descriptor on endpoint 0.

Contents

USB Basics

The Freescale K20 Family and their USB module

Part 1: The clocks

Part 2: The startup sequence

Part 3: The interrupt handler state machine

Part 4: Token processing & descriptors

Where to go from here

Conclusion

USB Basics

I will actually not be talking about these here as I am most definitely no expert. However, I will point to the page that I found most helpful when writing this:

http://www.usbmadesimple.co.uk/index.html

This site explained very clearly exactly what was going on with USB. Coupled with my previous knowledge, it was almost all I needed in terms of getting the protocol.

The Freescale K20 Family and their USB module

The one thing that I don’t like about all of these great microcontrollers that come out with USB support is that all of them have their very own special USB module which doesn’t work like anyone else. Sure, there are similarities, but there are no two exactly alike. Since I have a Teensy and the K20 family of microcontrollers seem to be relatively popular, I don’t feel bad about writing such specific software.

There are two documents I found to be essential to writing this driver:

  1. The family manual. Getting a correct version for the MK20DX256VLH7 (the processor on the Teensy) can be a pain. PJRC comes to the rescue here: http://www.pjrc.com/teensy/K20P64M72SF1RM.pdf (note, the Teensies based on the MK20DX128VLH5 use a different manual)
  2. The Kinetis Peripheral Module Quick Reference: http://cache.freescale.com/files/32bit/doc/quick_ref_guide/KQRUG.pdf. This specifies the initialization sequence and other things that will be needed for the module.

There are a few essential parts to understand about the USB module:

  • It needs a specific memory layout. Since it doesn’t have any dedicated user-accessible memory, it requires that the user specify where things should be. There are specific valid locations for its Buffer Descriptor Table (more on that later) and the endpoint buffers. The last one bit me for several days until I figured it out.
  • It has several different clock inputs and all of them must be enabled. Identifying the different signals is the most difficult part. After that, its not hard.
  • The module only handles the electrical aspect of things. It doesn’t handle sending descriptors or anything like that. The only real things it handles are the signaling levels, responding to USB packets in a valid manner, and routing data into buffers by endpoint. Other than that, its all user software.
  • The module can act as both a host (USB On-the-go (OTG)) and a device. We will be exclusively focusing on using it as a device here.

In writing this, I must confess that I looked quite a lot at the Teensyduino code along with the V-USB driver code (even though V-USB is for AVR and is pure software). Without these “references”, this would have been a very difficult project. Much of the structure found in the last to parts of this document reflects the Teensyduino USB driver since they did it quite efficiently and I didn’t spend a lot of time coming up with a “better” way to do it, given the scope of this project. I will likely make more changes as I customize it for my end use-case.

Part 1: The clocks

The K20 family of microcontrollers utilizes a miraculous hardware module which they call the “Multipurpose Clock Generator” (hereafter called the MCG). This is a module which basically allows the microcontroller to take any clock input between a few kilohertz and several megahertz and transform it into a higher frequency clock source that the microcontroller can actually use. This is how the Teensy can have a rated speed of 96Mhz but only use a 16Mhz crystal. The configuration that this project uses is the Phase Locked Loop (PLL) from the high speed crystal source. The exact setup of this configuration is done by the sysinit code.

The PLL operates by using a divider-multiplier setup where we give it a divisor to divide the input clock frequency by and then a multiplier to multiply that result by to give us the final clock speed. After that, it heads into the System Integration Module (SIM) which distributes the clock. Since the Teensy uses a 16Mhz crystal and we need a 96Mhz system clock (the reason will become apparent shortly), we set our divisor to 4 and our multiplier to 24 (see common.h). If the other type of Teensy 3 is being used (the one with the MK20DX128VLH5), the divisor would be 8 and the multiplier 36 to give us 72Mhz.

Every module on a K20 microcontroller has a gate on its clock. This saves power since there are many modules on the microcontroller that are not being used in any given application. Distributing the clock to each of these is expensive in terms of power and would be wasted if that module wasn’t used. The SIM handles this gating in the SIM_SCGC* registers. Before using any module, its clock gate must be enabled. If this is not done, the microcontroller will “crash” and stop executing when it tries to talk to the module registers (I think a handler for this can be specified, but I’m not sure). I had this happen once or twice while messing with this. So, the first step is to “turn on” the USB module by setting the appropriate bit in SIM_SCGC4 (per the family manual mentioned above, page 252):

Now, the USB module is a bit different than the other modules. In addition to the module clock it needs a reference clock for USB. The USB module requires that this reference clock be at 48Mhz. There are two sources for this clock: an internal source generated by the MCG/SIM or an external source from a pin. We will use the internal source:

The first line here selects that the USB reference clock will come from an internal source. It also specifies that the internal source will be using the output from the PLL in the MCG (the other option is the FLL (frequency lock loop), which we are not using). The second line sets the divider needed to give us 48Mhz from the PLL clock. Once again there are two values: The divider and the multiplier. The multiplier can only be 1 or 2 and the divider can be anywhere from 1 to 16. Since we have a 96Mhz clock, we simply divide by 2 (the value passed is a 1 since 0 = “divide by 1”, 1 = “divide by 2”, etc). If we were using the 72Mhz clock, we would first multiply by 2 before dividing by 3.

With that, the clock to the USB module has been activated and the module can now be initialized.

Part 2: The startup sequence

The Peripheral Module Quick Reference guide mentioned earlier contains a flowchart which outlines the exact sequence needed to initialize the USB module to act as a device. I don’t know if I can copy it here (yay copyright!), but it can be found on page 134, figure 15-6. There is another flowchart specifying the initialization sequence for using the module as a host.

Our startup sequence goes as follows:

The first two steps were covered in the last section. The next one is relatively straightfoward: We ask the module to perform a “reset” on itself. This places the module to its initial state which allows us to configure it as needed. I don’t know if the while loop is necessary since the manual says that the reset bit always reads low and it only says we must “wait two USB clock cycles”. In any case, enough of a wait seems to be executed by the above code to allow it to reset properly.

The next section (4: Set BDT base registers) requires some explanation. Since the USB module doesn’t have a dedicated memory block, we have to provide it. The BDT is the “Buffer Descriptor Table” and contains 16 * 4 entries that look like so:

“desc” is a descriptor for the buffer and “addr” is the address of the buffer. The exact bits of the “desc” are explained in the manual (p. 971, Table 41-4), but they basically specify ownership of the buffer (user program or USB module) and the USB token that generated the data in the buffer (if applicable).

Each entry in the BDT corresponds to one of 4 buffers in one of the 16 USB endpoints: The RX even, RX odd, TX even, and TX odd. The RX and TX are pretty self explanatory…the module needs somewhere to read the data its going to send and somewhere to write the data it just received. The even and odd are a configuration that I have seen before in the PIC 18F4550 USB module: Ping-pong buffers. While one buffer is being sent/received by the module, the other can be in use by user code reading/writing (ping). When the user code is done with its buffers, it swaps buffers, giving the usb module control over the ones it was just using (pong). This allows seamless communication between the host and the device and minimizes the need for copying data between buffers. I have declared the BDT in my code as follows:

One caveat of the BDT is that it must be aligned with a 512-byte boundary in memory. Our code above showed that only 3 bytes of the 4 byte address of “table” are passed to the module. This is because the last byte is basically the index along the table (the specification of this is found in section 41.4.3, page 970 of the manual). The #define directly above the declaration is a helper macro for referencing entries in the table for specific endpoints (this is used later in the interrupt). Now, accomplishing this boundary alignment requires some modification of the linker script. Before this, I had never had any need to modify a linker script. We basically need to create a special area of memory (in the above, it is called “.usbdescriptortable” and the attribute declaration tells the compiler to place that variable’s reference inside of it) which is aligned to a 512-byte boundary in RAM. I declared mine like so:

The position of this in the file is mildly important, so looking at the full linker script would probably be good. This particular declaration I more or less lifted from the Teensyduino linker script, with some changes to make it fit into my linker script.

Steps 5-6 set up the interrupts. There is only one USB interrupt, but there are two registers of flags. We first reset all of the flags. Interestingly, to reset a flag we write back a ‘1’ to the particular flag bit. This has the effect of being able to set a flag register to itself to reset all of the flags since a flag bit is ‘1’ when it is triggered. After resetting the flags, we enable the interrupt in the NVIC (Nested Vector Interrupt Controller). I won’t discuss the NVIC much, but it is a fairly complex piece of hardware. It has support for lots and lots of interrupts (over 100) and separate priorities for each one. I don’t have reliable code for setting interrupt priorities yet, but eventually I’ll get around to messing with that. The “enable_irq()” call is a function that is provided in arm_cm4.c and all that it does is enable the interrupt specified by the passed vector number. These numbers are specified in the datasheet, but we have a #define specified in the mk20d7 header file (warning! 12000 lines ahead) which gives us the number.

The very last step in initialization is to set the internal pullup on D+. According to the USB specification, a pullup on D- specifies a low speed device (1.2Mbit/s) and a pullup on D+ specifies a full speed device (12Mbit/s). We want to use the higher speed grade. The Kinetis USB module does not support high speed (480Mbit/s) mode.

Part 3: The interrupt handler state machine

The USB protocol can be interpreted in the context of a state machine with each call to the interrupt being a “tick” in the machine. The interrupt handler must process all of the flags to determine what happened and where to go from there.

The above code will be executed whenever the IRQ for the USB module fires. This function is set up in the crt0.S file, but with a weak reference, allowing us to override it easily by simply defining a function called USBOTG_IRQHandler. We then proceed to handle all of the USB interrupt flags. If we don’t handle all of the flags, the interrupt will execute again, giving us the opportunity to fully process all of them.

Reading through the code is should be obvious that I have not done much with many of the flags, including USB sleep, errors, and stall. For the purposes of this super simple driver, we really only care about USB resets and USB token decoding.

The very first interrupt that we care about which will be called when we connect the USB device to a host is the Reset. The host performs this by bringing both data lines low for a certain period of time (read the USB basics stuff for more information). When we do this, we need to reset our USB state into its initial and ready state. We do a couple things in sequence:

  1. Initialize the buffers for endpoint 0. We set the RX buffers to point to some static variables we have defined which are simply uint8_t arrays of length “ENDP0_SIZE”. The TX buffers are reset to null since nothing is going to be transmitted. One thing to note is that the ODDRST bit is flipped on in the USB0_CTL register. This is very important since it “syncronizes” the USB module with our code in terms of knowing whether the even or odd buffer should be used next for transmitting. When we do ODDRST, it sets the next buffer to be used to be the even buffer. We have a “user-space” flag (endp0_odd) which we reset at the same time so that we stay in sync with the buffer that the USB module is going to use.
  2. We enable endpoint 0. Specifically, we say that it can transmit, receive, and handshake. Enabled endpoints always handshake, but endpoints can either send, receive, or both. Endpoint 0 is specified as a reading and writing endpoint in the USB specification. All of the other endpoints are device-specific.
  3. We clear all of the interrupts. If this is a reset we obviously won’t be doing much else.
  4. Set our USB address to 0. Each device on the USB bus gets an address between 0 and 127. Endpoint 0 is reserved for devices that haven’t been assigned an address yet (i.e. have been reset), so that becomes our address. We will receive an address later via a command sent to endpoint 0.
  5. Activate all necessary interrupts. In the previous part where we discussed the initialization sequence we only enabled the reset interrupt. After being reset, we get to enable all of the interrupts that we will need to be able to process USB events.

After a reset the USB module will begin decoding tokens. While there are a couple different types of tokens, the USB module has a single interrupt for all of them. When a token is decoded the module gives us information about what endpoint the token was for and what BDT entry should be used. This information is contained in the USB0_STAT register.

The exact method for processing these tokens is up to the individual developer. My choice for the moment was to make a dynamic jump table of sorts which stores 16 function pointers which will be called in order to process the tokens. Initially, these pointers point to dummy functions that do nothing. The code for the endpoint 0 handler will be discussed in the next section.

Our code here uses USB0_STAT to determine which endpoint the token was decoded for, finds the appropriate function pointer, and calls it with the value of USB0_STAT.

Part 4: Token processing & descriptors

This is one part of the driver that isn’t something that must be done a certain way, but however it is done, it must accomplish the task correctly. My super-simple driver processes this in two stages: Processing the token type and processing the token itself.

As mentioned in the previous section, I had a handler for each endpoint that would be called after a token was decoded. The handler for endpoint 0 is as follows:

The very first step in handling a token is determining the buffer which contains the data for the token transmitted. This is done by the first statement which finds the appropriate address for the buffer in the table using the BDT_INDEX macro which simply implements the addressing form found in Figure 41-3 in the family manual.

After determining where the data received is located, we need to determine which token exactly was decoded. We only do things with four of the tokens. Right now, if a token comes through that we don’t understand, we don’t really do anything. My thought is that I should be initiating an endpoint stall, but I haven’t seen anywhere that specifies what exactly I should do for an unrecognized token.

The main token that we care about with endpoint 0 is the SETUP token. The data attached to this token will be in the format described by setup_t, so the first step is that we dereference and cast the buffer into which the data was loaded into a setup_t. This token will be stored statically since we need to look at it again for tokens that follow, especially in the case of the IN token following the request to be assigned an address.

One part of processing a setup token that tripped me up for a while was what the next DATA state should be. The USB standard specifies that the data in a frame is either marked DATA0 or DATA1 and it alternates by frame. This information is stored in a flag that the USB module will read from the first 4 bytes of the BDT (the “desc” field). Immediately following a SETUP token, the next DATA transmitted must be a DATA1.

After this, the setup function is run (more on that next) and as a final step, the USB module is “unfrozen”. Whenever a token is being processed, the USB module “freezes” so that processing can occur. While I haven’t yet read enough documentation on the subject, it seems to me that this is to give the user program some time to actually handle a token before the USB module decodes another one. I’m not sure what happens if the user program takes to long, but I imagine some error flag will go off.

The guts of handling a SETUP request are as follows:

This is the part that took me the longest once I managed to get the module talking. Handling of SETUP tokens on endpoint 0 must be done in a rather exact fashion and the slightest mistake gives some very cryptic errors.

This is a very very very minimalistic setup token handler and is not by any means complete. It does only what is necessary to get the computer to see the device successfully read its descriptors. There is no functionality for actually doing things with the USB device. Most of the space is devoted to actually returning the various descriptors. In this example, the descriptor is for a device with a single configuration and a single interface which uses no additional endpoints. In a real device, this would almost certainly not be the case (unless one uses V-USB…this is how V-USB sets up their device if no other endpoints are compiled in).

The SETUP packet comes with a “request” and a “type”. We process these as one word for simplicity. The above shows only the necessary commands to actually get this thing to connect to a Linux machine running the standard USB drivers that come with the kernel. I have not tested it on Windows and it may require some modification to work since it doesn’t implement all of the necessary functionality. A description of the functionality follows:

  • Set address (0x0500): This is a very simple command. All it does is wait for the next IN token. Upon receipt of this token, the address is considered “committed” and the USB module is told of its new address (see the endpoint 0 handler function above (not the setup handler)).
  • Set configuration (0x0900): This command can be complex, but I have stripped it down for the purposes of this example. Normally, during this command the USB module would be set up with all the requisite BDT entries for the endpoints described by the selected configuration. Since we only have one possible configuration and it doesn’t use any additional endpoints, we basically do nothing. Once I start added other endpoints to this, all of the setup for those endpoints will go in here. This is the equivalent of the RESET handler for non-zero endpoints in terms of the operations that occur. If the Set Interface command was implemented, it would have similar functionality. More about this command can be read in the referenced USB basics website.
  • Get descriptor (0x0680, 0x0681): In reality, this is two commands: Get descriptor and get interface. However, due to the structure we have chosen in storing the descriptors, these two commands can be merged. This is the most complex part of this particular driver and is influenced heavily by the way things are done with the Teensyduino driver since I thought they had a very efficient pattern. Basically, it uses the wIndex and wValue to find a pointer to some data to return, whether that be the device descriptor, the configuration descriptor, a string, or something else. In our case, we have only the device descriptor and the configuration descriptor. Adding a string would be trivial, however, and the exact wIndex and wValue combination for that is described in the USB basics. The wIndex for strings matches with any of the several i* (iManufacturer, iProduct, etc) which may be specified.
  • default: When an unrecognized command is received, we enter a stall. This is basically the USB way of saying “uhh…I don’t know what to do here” and requires the host to un-stall the endpoint before it can continue. From what I gather, there isn’t really much the user code has to do other than declare that a stall has occurred. The USB module seems to take care of the rest of that.

After handling a command and determining that it isn’t a stall, the transmission is set up. At the moment, I only have transmission set up for a maximum of 64 bytes. In reality, this is limited by the wLength transmitted with the setup packet (note the if statement before the call to usb_endp0_transmit), but as far as I have seen this is generally the same as the length of the endpoint (I could be very wrong here…so watch out for that one). However, it would be fairly straightfoward to allow it to transmit more bytes: Upon receipt of an IN token, just check if we have reached the end of what we are supposed to transmit. If not, point the next TX buffer to the correct starting point and subtract the endpoint size from the remaining length until we have transmitted all of the bytes. Although the endpoint size is 64 bytes, it is easy to transmit much more than that; it just takes multiple IN requests. The data length is given by the descriptors, so the host can determine when to stop sending IN requests.

During transmission, both the even and data flags are toggled. This ensures that we are always using the correct TX buffer (even/odd) and the DATA flag transmitted is valid.

The descriptors are the one part that can’t really be screwed up here. Screwing up the descriptors causes interesting errors when the host tries to communicate. I did not like how the “reference” usb drivers I looked at generally defined descriptors: They used a char array. This works very well for the case where there are a variable number of entries in the descriptor, but for my purposes I decided to use named structs so that I could match the values I had specified on my device to values I read from the host machine without resorting to counting bytes in the array. It’s simply for easier reading and doesn’t really give much more than that. It may even be more error prone because I am relying on the compiler packing the struct into memory in the correct order for transmission and in later versions I may end up using the char array method.

I won’t delve into a long and drawn out description of what the USB descriptor has in it, but I will give a few points:

  • In Linux, the device descriptor is requested first and then the configuration descriptor after that. They are two separate commands, hence the two separate descriptor entries in my descriptor table.
  • The device descriptor must NOT be “const”. For my compiler at least, this causes it to be placed into flash which, while a perfectly valid memory address that in general can be read, is inaccessible to the USB module. I spent a long time banging my head on this one saying “but it should work! why doesn’t it work???” Moral of the story: Anything that is pointed to by a BDT entry (transmit buffers, receive buffers) must be located in main RAM, not in the flash. It must not be const.
  • A device must have at least one configuration. Linux, at least, didn’t seem to like it very much when there were zero configurations and would put lots of errors into my log.
  • The configuration needs to have at least one interface. Specifying no interfaces caused the same problems as not specifying any configurations.
  • The configuration indices (bConfigurationValue) are 1-based and the interface indices (bInterfaceNumber) are zero based. I haven’t fooled around with these enough to test the veracity of this claim fully, but it was the only configuration that I managed to get things working in.
  • The length values are very important. If these are not correct, the host will have some serious troubles reading the descriptors. I spend a while troubleshooting these. The main one to make sure of is the wTotalLength value in the configuration descriptor. Most of the others are pretty much always going to be the same.

Where to go from here

The driver I have implemented leaves much to be desired. This isn’t meant to be a fully featured driver. Instead, its meant to be something of an introduction to getting the USB module to work on the bare metal without the support of some external dependency. A few things that would definitely need to be implemented are:

  • The full set of commands for the endpoint 0 SETUP token processing
  • A more expansive configuration that allows for having some bulk endpoints for sending data. The 64-byte limitation of packet size for endpoint 0 can cause some issues when attempting to actually utilize the full 12Mbit/s bandwidth. The USB protocol does actually add overhead and the less times that a token has to be invoked, the better.
  • Strings in the configuration. Right now, the configuration is essentially “blank” because it uses a shared VID/PID and doesn’t specify a manufacturer, product, or serial number. It would be rather hard to identify this device using libusb on a system with multiple devices using that VID/PID combination.
  • Real error handling. Right now, the interrupt basically ignores the errors. In a real application, these would need to be handled.
  • A better structure. I am not a real fan of how I have structured this, but my idea was to make it “expandable” without needing to recompile usb.c every time a change was made. It doesn’t achieve that yet, but in future iterations I hope to have a relatively portable usb driver module that I can port to other projects without modification, placing the other device-specific things into another, mimimalistic, file.

Conclusion

I can only hope that this discussion has been helpful. I spent a long time reading documentation, writing code, smashing my keyboard, and figuring things out and I would like to see that someone else could benefit from this. I hope as I learn more about using the modules on my Teensy that I will become more competent in understanding how many of the systems I rely on on a daily basis function.

The code I have included above isn’t always complete, so I would definitely recommend actually reading the code in the repository referenced at the beginning of this article.

If there are any mistakes in the above, please let me know in the comments or shoot me an email.

A new server

So for the past couple months my server has been going on and off due to the fact that rackspace increased their retirements of swapping and such. I made the swap to Amazon EC2 today and so over the next couple weeks we’ll see how this works out.

Teensy 3.1 Bare-Metal

Introduction

A couple of weeks ago I saw a link on hackaday to an article by Karl Lunt about using the Teensy 3.1 without the Arduino IDE and building for the bare metal. I was very intrigued as the Arduino IDE was my only major beef with developing stuff for the Teensy 3.1 and I wanted to be able to do things without having to use the IDE. I read through the article and although it was geared towards windows, I decided to try to adapt it to my development style. There were a few things I wanted to do:

  • No additional code dependencies other than the teensyduino installation which I already had
  • Use local binaries for compilation, not the ones included with teensyduino (it just felt uncomfortable to use theirs)
  • Separation of src, obj, and bin directories
  • Mixture of c and cpp files in the src directory
  • Not needing to explicitly list the files in the src directory to compile
  • Selective inclusion of features from the teensyduino installation

I have very little experience writing more complex Makefiles. When I say “complex” I am referring to makefiles which have the src, obj, bin separation and pull in objects from multiple sources. While this may not seem complex to many people, its something I have very little experience actually doing by hand (I would normally use a generator of some sort).

I’m writing this in the hope that those without mad Makefile skills, such as myself, can liberate themselves from the Arduino IDE when developing for an awesome platform like the Teensy 3.1.

All code for this example can be found here: https://github.com/kcuzner/teensy31-blinky-bare-metal

Prerequisites

As my first order of business, I located the arm-none-eabi binaries for my linux distribution. These can also be found for Windows as noted in Karl Lunt’s article. Random sidenote: I found this description of why arm-none-eabi is called arm-none-eabi. Very informative. Anyway, for those who run archlinux, the following packages are needed:

  • arm-none-eabi-gcc (contains the compilers)
  • arm-none-eabi-binutils (contains the linker, objdump, and other things for manipulating the binaries into hex files)
  • make (we are using a makefile…)

Hopefully this gives a bit of a hint on what packages may need to be installed on other systems. For Windows, the compiler is here and make can be found here or by googling around. I haven’t tested any of this on Windows and would advocate using Linux for this, but it shouldn’t be hard to modify the Makefile for Windows.

My Flow

For C and C++ development I have a particular flow that I like to follow. This is heavily influenced by my usage of Code::Blocks and Visual Studio. I like to have a src directory where I put all of my sources, an include directory where I put all of my headers, an obj directory for all the obj, d, & lst files, and a bin directory for my executable output. I’ve always had such a hard time with raw Makefiles because I could never quite get that directory structure working. I was never quite satisfied with my feeble Makefile attempts which ended up placing the object files in the root directory where the sources had to be. This Makefile represents my first time I was ever able to actually have a real bin, obj, src structure that works.

Compiling object files to obj & looking in src for source

A working description of this can be found in the Makefile in my github repository I mentioned earlier.

Makefiles work by defining a series of “targets” which have “dependencies”. Every dependency can also be the name of a target and a target may have multiple ways of being resolved (this I never realized before). So, here is the parts of the Makefile which enable searching in src for both c and cpp and doing specific actions for each, comping them into the obj directory:

Each section above has a specific purpose and the order can be rather important. The first part uses $(wildcard …) to pick up all of the C++ and C files. The CPP_FILES variable, for example, will become “src/file1.cpp src/file2.cpp src/etc.cpp” if we had “file1.cpp”, “file2.cpp” and “etc.cpp” in the src directory. Similarly, the C_FILES would pick up any files in src with a c file extension. Next, the filenames are transformed into object filenames living in the obj directory. This is done by first changing the file extension of the files to .o using the $(CPP_FILES:.cpp=.o) or $(C_FILES:.c=.o) syntax. However, these files still look like they are in the src directory (e.g. src/file1.o) so the directory is next stripped off each file using $(nodir…). Removing the directory doesn’t allow for a nested src directory, but that wasn’t one of our objectives here. At this point, the files are just names with no directories (e.g. file1.o) and so the last step is to change them to live in the obj directory using $(addprefix $(OBJDIR)/,..). This completes our transformation, populating OBJ_FILES to look like “obj/file1.o obj/file2.o” etc.

The next part is where we take that list of object files and use them as dependencies for a target. Targets are defined by <target name>: <dependency list> followed by a list of commands to execute after resolving the dependencies. IMPORTANT: The list of commands needs to be indented by a tab (t) character. Spaces will not work (it will say something like “missing separator” with a line number). A target is anything that we pass into make. The default target is ‘all’. The “dependencies” are files which much be “up to date” before the target is run.

In our example, we use $(OBJ_FILES) as a dependency of “$(OUTPUTDIR)/$(PROJECT).elf” which is required as a dependency of “build”. This tells make that when we run “make build”, it needs to try to resolve the dependency of “bin/<project>.elf” which in turn needs to resolve “obj/file1.o”, “obj/file2.o”, and “obj/etc.o” (going from our example in the previous paragraph). This is where the next couple targets come in. A target will only be executed if it can find some rule to resolve all of the dependencies. We will use “obj/file1.o” as an example here. There are 2 targets with that name, actually: “$(OBJDIR)/%.o: $(SRCDIR)/%.c” and “$(OBJDIR)/%.o: $(SRCDIR)/%.cpp”. It would be good to note that the target names here the exact same even though the dependencies are different. Now, how does “$(OBJDIR)%.o” match “obj/file1.o”? A Makefile does something called “pattern matching” when the % sign is used. It says “match something that looks like $(OBJDIR)<some file>.o” which our “obj/file1.o” happens to match. The cool part is that once the target name is resolved using a %, the dependencies get to use % to substitute the exact same thing. Thus, our % here is “file1”, so it follows that its dependency must be “$(SRCDIR)/file1.c”. Now, our example used “file1.cpp”, not “file1.c” and this is where defining multiple targets with the same names but different dependencies comes in. A target will only be executed if the dependencies can be resolved to either an actual file and/or another target. Our first target won’t be a match since it says that the source file should be a C file. So, it goes to the next target that matches the name which has a dependency of “$(SRCDIR)/file1.cpp”. This one matches, and so commands following that target are executed.

When executing a target (“$(OBJDIR)/%.o: $(SRCDIR)/%.cpp” in our example), there are some special variables which are available for use. These are described here, but I will discuss two important ones that I used: $@ and $<. $@ is the name of the target (so, “obj/file.o” in our case) and $< is the name of the first dependency (“src/file.cpp” in our case). This lets us pass these arguments into the commands that we execute. Our Makefile will first create the obj directory by calling “mkdir -p $(dir $@)” which is translated into “mkdir -p obj” since $(dir $@) will give us “obj”. Next, we actually compile the $< (which is translated to “src/file.cpp”), outputting it to $< which is translated to “obj/file.o”.

Outputting everything to bin

Compared to the pattern matching and multiple target definitions that we discussed above, this is comparatively simple. We simply get to prefix all of our “binary” output files with some directory which is set as $(OUTPUTDIR) in my Makefile. Here is an example:

We see here that any output that we are creating as a result of the compilation (.elf, .hex, .bin) is going to end up in $(OUTPUTDIR). Futher, we see that our “all” target asks the Makefile to create both a bin file and a hex file along with two other targets called “stats” and “dump”. These are just scripts that execute the “size” and “objdump” commands on our bin file.

Using Teensyduino without compiling everything

This was by far the most frustrating part to get working. Everything about the makefiles was readily available online, with some serious googling. However, getting things to actually compile was a little different story.

The thing that makes this complex is the fact that it seems the Teensyduino libraries were not designed to be used independently of each other. I will cover, in order, what steps I had to take in order to get this to work.

The most important file we need is called “mk20dx128.c”. This sets up a lot of things relating to interrupts along with the Phase Lock Loop (PLL) which controls the speed of the Teensy’s processor. Without this configuration, we don’t get interrupts and the processor runs at a pitiful 16Mhz. The only problem is that “mk20dx128” references a few functions that are either part of the standard library and not used often (making them difficult to search for) or are defined in other files, increasing our dependency count.

My first mistake was explicitly using the linker to link all of my object files (wait…aren’t we supposed to use the linker? Read on.). Since arm-none-eabi is not dependent on a specific architecture, it doesn’t know which standard library (libc) to use. This results in an undefined reference to “__libc_init_array()”, a function used during the initialization phase of a program which is not often invoked in code outside the standard library itself. mk20dx128.c uses this function in its custom startup code which prepares the processor for running our program. To solve this, I wanted to tell the linker that I was using a cortex-m4 cpu so that it would know which libc to include and thereby resolve the reference. However, this proved difficult to do when directly invoking the linker. Instead, I took a hint from the Makefile that comes with Teensyduino and used the following command to link the objects:

Which more or less translates to (using our example from earlier):

We would have thought that we should be using arm-none-eabi-ld instead of arm-none-eabi-gcc. However, by using arm-non-eabi-gcc I was able to pass the argument “-mcpu=cortex-m4” which then allowed GCC to instruct the linker which standard library to use. Wonderful, right? So all of our problems are solved? Not yet.

The next thing is that mk20dx128.c has a lot of external dependencies. It uses a function defined in pins_teensy.c which in turn requires functions defined in both analog.c and usb_dev.c which opens another can of worms. Ugh. I didn’t want this many dependencies and I couldn’t see a way to escape compiling nearly the entire Teensyduino library just to run my simple blinking program. Then, it dawned on me: I could use the same technique that mk20dx128.c uses to define its ISRs to “define” the functions that pins_teensy.c was calling that I didn’t really want. So, I made a file called “shim.c” which contained the following:

I decided that I would include “yield.c” and “analog.c” since those weren’t too big. This left just the usb stuff. The only function that was actually called from pins_teensy.c was “usb_init”. What the above statement says to the compiler is “I am defining usb_init(void) here (which points to unused_void(void)) unless you find another definition of usb_init(void) somewhere”. The “weak” attribute makes this “strong” symbol of usb_init a “weak” symbol reference to which is basically the same as just making a declaration (in contrast to the definition a function, which is usually a strong reference). Sidenote: A program can have any number of weak symbol references to a specific function/variable (declarations), but only one strong symbol reference (definition) of that function/variable. The “alias” attribute allows us to say “when I say usb_init I really mean unused_void”. The end result of this is that if nobody defines usb_init(void) anywhere, as would be situation if I were to decide not to include usb_dev.c, any calls to usb_init(void) will actually call unused_void(void). However, if somebody did define usb_init(void), my definition of usb_init would be ignored in favor of using their definition. This lets me include usb support in the future if I wanted to. Isn’t that cool? That fixed all of my reference issues and let me actually build the project.

Conclusion

Armed with my new Makefile and a better understanding of how the Teensy 3.1 works from a software perspective, I managed to compile and upload my “blinky” program which just blinks the onboard LED (pin 13) on and off every 1/4 second. The overall program size was 3% of the total space, which is much more reasonable compared to the 10-20% it was taking when compiled using the Arduino IDE.

Again, all files from this escapade can be found here: https://github.com/kcuzner/teensy31-blinky-bare-metal

First thoughts on the Teensy 3.1

Wow it has been a while; I have not written since August.

I entered a contest of sorts this past week which involves building an autonomous turret which uses an ultrasonic sensor to locate a target within 10 feet and fire at it with a tiny dart gun. The entire assembly is to be mounted on servos. This is something my University is doing as an extra-curricular for engineers and so when a friend of mine asked if I wanted to join forces with him and conquer, I readily agreed.

The most interesting part to me, by far, is the processor to be used. It is going to be a Teensy 3.1:

Teensy 3.1

Teensy 3.1

This board contains a Freescale ARM Cortex-M4 microcontroller along with a smaller non-user-programmable microcontroller for assistance in the USB bootloading process (the exact details of that interaction are mostly unknown to me at the moment). I have never used an ARM microcontroller before and never a microcontroller with as many peripherals as this one has. The datasheet is 1200 pages long and is not really even being very verbose in my opinion. It could easily be 3000 pages if they included the level of detail usually included in AVR and PIC datasheets (code examples, etc). The processor runs at 96Mhz as well, making it the most powerful embedded computer I have used aside from my Raspberry Pi.

The Teensy 3.1 is Arduino-compliant and is designed that way. However, it can also be used without the Arduino software. I have not used an Arduino before since I rather enjoy using microcontrollers in a bare-bones fashion. However, it is become increasingly more difficult for me to be able to experiment with the latest in microcontroller developments using breadboards since the packages are becoming increasingly more surface mount.

The Arduino IDE

Oh my goodness. Worst ever. Ok, not really, but I really have a hard time justifying using it other than the fact that it makes downloading to the Teensy really easy. This post isn’t meant to be a review of the arduino IDE, but the editor could use some serious improvements IMHO:

  • Tab indentation level: Some of us would like to use something other than 2 spaces, thank you very much. We don’t live in the 70’s where horizontal space is at a premium and I prefer 4 spaces. Purely personal preference, but I feel like the option should be there
  • Ability to reload files: The inability to reload the files and the fact that it seems to compile from a cache rather than from the file itself makes the arduino IDE basically incompatible with git or any other source control system. This is a serious problem, in my opinion, and requires me to restart the editor frequently whenever I check out a different branch.
  • Real project files: I understand the aim for simplicity here, but when you have a chip with 256Kb of flash on it, your program is not going to be 100 lines and fit into one file. At the moment, the editor just takes everything in the directory and compiles it by file extension. No subdirectories and every file will be displayed as a separate tab with no way to close it. I am in the habit of separating my source and not having the ability to structure my files how I please really makes me feel hampered. To make matters worse, the IDE saves the original sketch file (which is just a cpp file that will be run through their preprocessor) with its own special file extension (*.ino) which makes it look like it should be a project file, but in reality it is not.

There are few things I do like, however. I do like their library of things that make working with this new and foreign processor rather easy. I also like that their build system is very cross-platform and easy to use.

First impression of the processor

I must first say that the level of work that has gone into the surrounding software (the header files, the teensy loader, etc) truly shows and makes it a good experience to use the Teensy, even if the Arduino IDE sucks. I tried a Makefile approach using Code::Blocks, but it was difficult for me to get it to compile cross-platform and I was afraid that I would accidentally overwrite some bootloader code that I hadn’t known about. So, I ended up just going with the Ardiuno IDE for safety reasons.

The peripherals on this processor are many and it is hard at times to figure out basic functions, such as the GPIO. The manual for the peripherals is in the neighborhood of 60 chapters long, with each chapter describing a peripheral. So far, I have messed with just the GPIOs and pin interrupts, but I plan on moving on to the timer module very soon. This project likely won’t require the DMA or the variety of onboard bus modules (CAN, I2C, SPI, USB, etc), but in the future I hope to have a Teensy of my own to experiment on. The sheer number of registers combined with the 32-bit width of everything is a totally new experience for me. Combine that with the fact that I don’t have to worry as much about the overhead of using certain C constructs (struct and function pointers for example) and I am super duper excited about this processor. Tack on the stuff that PJRC created for using the Teensy such as the nice header files and the overall compatibility with some Arduino libraries, and I have had an easier time getting this thing to work than with most of my other projects I have done.

Conclusion

Although the Teensy is for a specific contest project right now, at the price of $19.80 for the amount of power that it gives, I believe I will buy one for myself to mess around with. I am looking forward to getting more familiar with this processor and although I resent the IDE I have to work with at the moment, I hope that I will be able to move along to better compilation options that will let me move away from the arduino IDE.

Pop ‘n Music controller…AVR style

Every time I do one of these bus emulation projects, I tell myself that the next time I do it I will use an oscilloscope or DLA. However, I never actually break down and just buy one. Once more, I have done a bus emulation project flying blind. This is the harrowing tale:

Code & Schematics (kicad): https://github.com/kcuzner/pop-n-music-controller

Introduction

A couple of days ago, I was asked to help do some soldering for a modification someone was trying to do to a PS1 controller. He informed me that it was for the game Pop ‘n Music and that it required a special controller to be played properly. Apparently, official controllers can sell for $100 or more, so modifying an existing controller was the logical thing to do. After much work and pain, it was found that while modifying an existing controller was easy, it wasn’t very robust and could easily fall apart and so I built one using an ATMega48 and some extra components I had lying around. The microcontroller emulates the PSX bus which is used to communicate between the controller and the playstation/computer. As my reference for the bus, I used the following two web pages:

The complete schematics and software can be found on my github.

The first attempt: Controller mod

The concept behind the controller mod was simple: Run wires from the existing button pads to some arcade-style buttons arranged in the pattern needed for the controller. It worked well at first, but after a little while we began to have problems:

  • The style of pad that he purchased had conductive rubber covering all of the copper for the button landings. In order to solder to this, it was necessary to scrape off the rubber. This introduced a tendency for partially unclean joints, giving rise to cold connections. While with much effort I was able to mitigate this issue (lots of scraping and cleaning), the next problem began to manifest itself.
  • The copper layout for each button pad was of a rather minimalist design. While some pads shown online had nice large areas for the button to contact, this particular controller had 50-100 mil lines arranged in a circular pattern rather than one huge land. While I imagine this is either economical or gives better contact, it sure made soldering wires onto it difficult. I would get the wire soldered, only to have it decide that it wanted to come off and take the pad with it later. This was partly due to bad planning on my part and using wire that wasn’t flexible enough, but honestly, the pads were not designed to be soldered to.
  • With each pad that lifted, the available space for the wires on certain buttons to be attached to began to become smaller and smaller. Some buttons were in the large land style and were very easy to solder to and the joints were strong (mainly the arrow pad buttons). The issue was with the start and select buttons (very narrow) and the X, square, triangle, and O buttons (100mil spiral thing mentioned earlier). Eventually, I was resorting to scraping the solder mask off and using 30awg wire wrapping wire to solder to the traces. It just got ridiculous and wasn’t nearly strong enough to hold up as a game controller.
  • In order for the controller to be used with a real playstation, rather than an emulator, the Left, Right, and Down buttons had to be pressed at the same time to signify to the game that it was a Pop ‘n Music controller. Emulators generally can’t handle this sort of behavior when mapping the buttons around, so putting a switch was considered. However, any reliable switch (read: Nice shiny toggle switch) was around $3. Given the low cost aim of this project, it was becoming more economical to explore other options

So, we began exploring other options. I found this site detailing emulation of these controllers using either 74xx logic or a microcontroller. It is a very good resource, and is mostly correct about the protocol. After looking at the 74xx logic solution and totaling up the cost, I noticed that my $1.75 microcontroller along with the required external components would actually come out to be cheaper than buying 4 chips and sockets for them. Even better, I already had a microcontroller and all the parts on hand, so there was no need for shipping. So, I began building and programming.

AVR PSX Bus Emulation: The Saga of the Software

PSX controllers communicate using a bus that has a clock, acknowledge, slave select, psx->controller (command) line, and controller->psx (data) line. Yes, this looks a lot like an SPI bus. In fact, it is more or less identical to a SPI Mode 3 bus with the master-in slave-out line driven open collector. I failed to notice this fact until later, much to my chagrin. Communication is accomplished using packets that have a start signal followed by a command and waiting for a response from the controller. During the transaction, the controller declares its type, the number of words that it is going to send, and the actual controller state. I was emulating a standard digital controller, so I had to tell it that my controller type was 0x41, which is digital with 1 word data. Then, I had to send a 0x5A (start data response byte) and two bytes of button data. My initial approach involved writing a routine in C that would handle pin changes on INT0 and INT1 which would be connected to the command and clock lines. However, I failed to anticipate that the bus would be somewhere in the neighborhood of 250Khz-500Khz and this caused some serious performance problems and I was unable to complete a transaction with the controller host. So, I decided to try writing the same routine in assembly to see if I could squeeze every drop of performance out of it possible. I managed to actually get it to complete a transaction this way, but without sending button data. To make matters worse, every once in a while it would miss a transaction and this was quite noticeable when I made an LED change state with every packet received. It was very inconsistent and that was without even sending button data. I eventually realized the problem was with the fact that making the controller do so much between cycles of the clock line actually caused it to miss bits. So, I looked at the problem again. I noticed that the ATMega48A had an SPI module and that the PSX bus looked similar, but not exactly like, an SPI bus. However, running the bus in mode 3 with the data order reversed and the MISO driving the base of a transistor operating in an open-collector fashion actually got me to be able to communicate to the PSX bus on almost the first try. Even better, the only software change that had to be made was inverting the data byte so that the signal hitting the base of the transistor would cause the correct changes on the MISO line. So, I hooked up everything as follows:

Pop 'n Music Controller Schematic

Pop ‘n Music Controller Schematic

After doing that, suddenly I got everything to work. It responded correctly to the computer when asked about its inputs and after some optimization, stopped skipping packets due to taking too much time processing button inputs. It worked! Soon after getting the controller to talk to the computer, I discovered an error in the website I mentioned earlier that detailed the protocol. It mentioned that during transmission of the data about the buttons that the control line was going to be left high. While its a minor difference, I thought I might as well mention this site, which lists the commands correctly and was very helpful. As I mentioned before, one problem that was encoutered was that in order for the controller to be recognized as a pop-n-music controller by an actual playstation, the left, right, and down buttons must be pressed. However, it seems that the PSX->USB converter that we were using was unable to handle having those 3 pressed down at once. So, there needed to be a mode switch. The way for switching modes I came up with was to hold down both start and select at the same time for 3 seconds. After the delay, the modes would switch. The UI interaction for this is embodied in two LEDs. One LED is lit for when it is in PSX mode and the other when it is in emulator mode. When both buttons are pressed, both LEDs light up until the one for the previous mode shuts off. At first, I had the mode start out every time the controller was started in the same mode, no matter what the previous mode was before it was shut off. It soon became apparent that this wouldn’t do, and so I looked in to using the EEPROM to store the flag value I was using to keep the state of the controller. Strangely, it worked on the first try, so the controller will stay in the same mode from the last time it was shut off. My only fear is that switching the mode too much could degrade the EEPROM. However, the datasheet says that it is good for 100,000 erase/write cycles, so I imagine it would be quite a while before this happens and other parts of the controller will probably fail first (like the switches).

On to the hardware!

I next began assembly. I went the route of perfboard with individual copper pads around each hole because that’s what I have. Here are photos of the assembly, sadly taken on my cell phone because my camera is broken. Sorry for the bad quality…

Socket and PSX plug mouted

Socket and PSX plug mouted

Wiring between PSX plug and socket

Wiring between PSX plug and socket

Adding some transistors...first try

Adding some transistors…first try

Adding the transistors, try 2

Adding the transistors, try 2

Wiring almost done

Wiring almost done

Inside of switch box

Inside of switch box

The controller in action

The controller in action

Conclusion

So, with the controller in the box and everything assembled, it seems that all will be well with the controller. It doesn’t seem to miss keypresses or freeze and is able to play the game without too many hiccups (the audio makes it difficult, but that’s just a emulator tweaking issue). The best part about this project is that in terms of total work time, it probably took only about 16 hours. Considering that most of my projects take months to finish, this easily takes the cake as one of my quickest projects start to finish.

Raspberry Pi as an AVR Programmer

Introduction

Recently, I got my hands on a Raspberry Pi and one of the first things I wanted to do with it was to turn it into my complete AVR development environment. As part of that I wanted to make avrdude be able to program an AVR directly from the Raspberry Pi with no programmer. I know there is this linuxgpio programmer type that was recently added, but it is so recent that it isn’t yet included in the repos and it also requires a compile-time option to enable it. I noticed that the Raspberry Pi happens to expose its SPI interface on its expansion header and so I thought to myself, “Why not use this thing instead of bitbanging GPIOs? Wouldn’t that be more efficient?” Thus, I began to decipher the avrdude code and write my addition. My hope is that things like this will allow the Raspberry Pi to be used to explore further embedded development for those who want to get into microcontrollers, but blew all their money on the Raspberry Pi. Also, in keeping with the purpose that the Raspberry Pi was originally designed for, using it like this makes it fairly simple for people in educational surroundings to expand into different aspects of small computer and embedded device programming.

As my addition to avrdude, I created a new programmer type called “linuxspi” which uses the userspace SPI drivers available since around Linux ~2.6 or so to talk to a programmer. It also requires an additional GPIO to operate as the reset. My initial thought was to use the chip select as the reset output, but sadly, the documentation for the SPI functions mentioned that the chip enable line is only held low so long as the transaction is going. While I guess I could compress all the transactions avrdude makes into one giant burst of data, this would be very error prone and isn’t compatible with avrdude’s program structure. So, the GPIO route was chosen. It just uses the sysfs endpoints found in /sys/class/gpio to manipulate a GPIO chosen in avrdude.conf into either being in a hi-z input state or an output low state. This way, the reset can be connected via a resistor to Vcc and then the Raspberry Pi just holds reset down when it needs to program the device. Another consequence which I will mention here of choosing to use the Linux SPI drivers is that this should actually be compatible with any Linux-based device that exposes its SPI or has an AVR connected to the SPI; not just the Raspberry Pi.

Programming an AVR

Raspberry Pi Programming an AVR

Usage

So, down to the nitty gritty: How can I use it? Well, at the moment it is in a github repository at https://github.com/kcuzner/avrdude. As with any project that uses the expansion header on the Raspberry Pi, there is a risk that a mistake could cause your Raspberry Pi to die (or let out the magic smoke, so to speak). I assume no responsibility for any damage that may occur as a result of following these directions or using my addition to avrdude. Just be careful when doing anything involving hooking stuff up to the expansion port and use common sense. Remember to measure twice and cut once. So, with that out of the way, I will proceed to outline here the basic steps for installation and usage.

Installation

The best option here until I bother creating packages for it is to  do a git clone directly into a directory on the Raspberry Pi and build it from there on the Raspberry Pi itself. I remember having to install the following packages to get it to compile (If I missed any, let me know):

  • bison
  • autoconf
  • make
  • gcc
  • flex

Also, if your system doesn’t have a header at “linux/spi/spidev.h” in your path, you probably need to install that driver. I was using Arch Linux and it already had the driver there, so for all I know its always installed. You also should take a look to make sure that “/dev/spidev0.0” and “/dev/spidev0.1” or something like that exist. Those are the sort of endpoints that are to be used with this. If they do not exist, try executing a “sudo modprobe spi_bcm2708”. If the endpoints still aren’t there after that, then SPI support probably isn’t installed or enabled for your kernel.

After cloning the repo and installing those packages, run the “./boostrap” script which is found in the avrdude directory. This will run all the autoconf things and create the build scripts. The next step is to run “./configure” and wait for it to complete. After the configure script, it should say whether or not “linuxspi” is enabled or disabled. If it is disabled, it was not able to find the header I mentioned before. Then run “make” and wait for it to complete. Remember that the Raspberry Pi is a single core ARM processor and so building may take a while. Afterwards, simply do “sudo make install” and you will magically have avrdude installed on your computer in /usr/local. It would probably be worthwhile to note here that you probably want to uninstall any avrdude you may have had installed previously either manually or through a package manager. The one here is built on top of the latest version (as of May 26th, 2013), so it should work quite well and be all up to date and stuff for just using it like a normal avrdude. I made no changes to any of the programmer types other than the one I added.

To check to see if the avrdude you have is the right one, you should see an output similar to the following if you run this command (tiny-tim is the name of my Raspberry Pi until I think of something better):

Note that right under “linuxgpio” there is now a “linuxspi” driver. If it says “(not available)” after the “linuxspi” description, “./configure” was not able to find the “linux/spi/spidev.h” file and did not compile the linuxspi programmer into avrdude.

Configuration

There is a little bit of configuration that happens here on the Raspberry Pi side before proceeding to wiring it up. You must now decide which GPIO to sacrifice to be the reset pin. I chose 25 because it is next to the normal chip enable pins, but it doesn’t matter which you choose. To change which pin is to be used, you need to edit “/usr/local/etc/avrdude.conf” (it will be just “/etc/avrdude.conf” if it wasn’t built and installed manually like above). Find the section of the file that looks like so:

The “reset = ” line needs to be changed to have the number of the GPIO that you have decided to turn into the reset pin for the programmer. The default is 25, but that’s just because of my selfishness in not wanting to set it to something more generic and having to then edit the file every time I re-installed avrdude. Perhaps a better default would be “0” since that will cause the programmer to say that it hasn’t been set up yet.

Wiring

After setting up avrdude.conf to your desired configuration, you can now connect the appropriate wires from your Raspberry Pi’s header to your microchip. A word of extreme caution: The Raspberry Pi’s GPIOs are NOT 5V tolerant, and that includes the SPI pins. You must do either one of two things: a) Run the AVR and everything around it at 3.3V so that you never see 5V on ANY of the Raspberry Pi pins at any time (including after programming is completed and the device is running) or b) Use a level translator between the AVR and the SPI. I happen to have a level translator lying around (its a fun little TSSOP I soldered to a breakout board a few years back), but I decided to go the 3.3V route since I was trying to get this thing to work. If you have not ever had to hook up in-circuit serial programming to your AVR before, perhaps this would be a great time to learn. You need to consult the datasheet for your AVR and find the pins named RESET (bar above it), MOSI, MISO, and SCK. These 4 pins are connected so that RESET goes to your GPIO with a pullup resistor to the Vcc on your AVR, MOSI goes to the similarly named MOSI on the Raspberry Pi header, MISO goes to the like-named pin on the header, and SCK goes to the SPI clock pin (named SCLK on the diagram on elinux.org). After doing this and double checking to make sure 5V will never be present to the Raspberry Pi, you can power on your AVR and it should be able to be programmed through avrdude. Here is a demonstration of me loading a simple test program I made that flashes the PORTD LEDs:

There are two major things to note here:

  • I set the programmer type (-c option) to be “linuxspi”. This tells avrdude to use my addition as the programming interface
  • I set the port (-P option) to be “/dev/spidev0.0”. On my Raspberry Pi, this maps to the SPI bus using CE0 as the chip select. Although we don’t actually use CE0 to connect to the AVR, it still gets used by the spidev interface and will toggle several times during normal avrdude operation. Your exact configuration may end up being different, but this is more or less how the SPI should be set. If the thing you point to isn’t an SPI device, avrdude should fail with a bunch of messages saying that it couldn’t send an SPI message.

Other than that, usage is pretty straightforward and should be the same as if you were using any other programmer type.

Future

As issues crop up, I hope to add improvements like changing the clock frequency and maybe someday adding TPI support (not sure if necessary since this is using the dedicated SPI and as far as I know, TPI doesn’t use SPI).

I hope that those using this can find it helpful in their fun and games with the Raspberry Pi. If there are any issues compiling and stuff, either open an issue on github or mention it in the comments here.

Lessons in game design…in a car!

For the greater part of this week I have been trapped in a car driving across the United States for my sister’s wedding. Of course, I had my trusty netbook with me and so I decided to do some programming. After discovering that I had unwittingly installed tons of documentation in my /usr/share/doc folder (don’t you love those computer explorations that actually reveal something?), I started building yet another rendition of Tetris in Python. I did several things differently this time and the code is actually readable and I feel like some structure things I learned/discovered/re-discovered should be shared here.

Game State Management

One problem that has constantly plagued my weak attempts at games has been an inability to do menus and manage whether the game is paused or not in a reasonably simple manner. Of course, I could always hack something together, but I could also write the whole thing in assembly language or maybe write it all as one big function in C. The issue is that if I program myself into a hole, I usually end up giving up a bit unless I am getting paid (then I generally bother thinking before programming so that I don’t waste people’s time). After finishing the game logic and actually getting things to work with the game itself, I remembered a funny tutorial I was once doing for OGRE which introduced a very simple game engine. The concept was one of a “stack” of game states. Using this stack, your main program basically injects input into and then asks a rendering from the state on the top of the stack. The states manipulate the stack, pushing a new state or popping themselves. When the stack is empty, the program exits.

My game state stack works by using an initial state that loads the resources (the render section gives back a loading screen). After it finishes loading the resources, it asks the manager to pop itself from the stack and then push on the main menu state. The menu state is quite simple: It displays several options where each option either does something immediate (like popping the menu from the stack to end the program in the case of the Quit option) or something more complex (like pushing a sub-menu state on to create a new game with some settings). After that there are states for playing the game, viewing the high scores, etc.

The main awesome thing about this structure is that switching states is so easy. Want to pause the game? Just push on a state that doesn’t do anything until it receives a key input or something, after which it pops itself. Feel like doing a complex menu system? The stack keeps track of the “breadcrumbs” so to speak. Never before have I been able to actually create an easily extensible/modification-friendly game menu/management system that doesn’t leave me with a headache later trying to understand it or unravel my spaghetti code.

The second awesome thing is that this helps encourage an inversion of control. Rather than the state itself dictating when it gets input or when it renders something, the program on top of it can choose whether it wants to render that state or whether it wants to give input to that state. I ended up using the render function like a game loop function as well and so if I wanted a state to sort of “pause” execution, I could simply stop telling it to render (usually by just pushing a state on top of it). My main program (in Python) was about 25 lines long and took care of setting up the window, starting the game states, and then just injecting input into the game state and asking the state to render a window. The states themselves could choose how they wanted to render the window or even if they wanted to (that gets into the event bubbling section which is next). It is so much easier to operate that way as the components are loosely tied to one another and there is a clear relationship between them. The program owns the states and the states know nothing about about the program driving them…only that their input comes from somewhere and the renderings they are occasionally asked to do go somewhere.

Event bubbling

When making my Tetris game, I wanted an easy to way to know when to update or redraw the screen rather than always redrawing it. My idea was to create an event system that would “notice” when the game changed somehow: whether a block had moved or maybe the score changed. I remembered of two event systems that I really really liked: C#’s event keyword plus delegate thing and Javascript’s event bubbling system. Some people probably hate both of those, but I have learned to love them. Mainly, its just because I’m new to this sort of thing and am still being dazzled by their plethora of uses. Using some knowledge I gleaned from my database abstraction project about the fun data model special function names in Python, I created the following:

My first thought when making this was to do it like C# events: super flexible, but no defined “way” to do them. The event dispatcher uses the same syntax as the C# events (+=, -= or __iadd__, __isub__) to add/remove handlers and also to call each handler (() or __call__). It also has the added functionality of optionally suppressing events by using them inside a “with” statement (which may actually be breaking the pattern, but I needed it to avoid some interesting redrawing issues). I would add EventDispatcher objects to represent each type of event that I wanted to catch and then pass an Event object into the event to send it off to the listening functions. However, I ran into an issue with this: Although I was able to cut down the number of events being sent and how far they propagated, I would occasionally lose events. The issue this caused is that my renderer was listening to find out where it should “erase” blocks and where it should “add” blocks and it would sometimes seem to forget to erase some of the blocks. I later discovered that I had simply forgotten to call the event during a certain function which was called periodically to move the Tetris blocks down, but even so, it got my started on the next thing which I feel is better.

Javascript events work by specifying types of events, a “target” or object in the focus of the event, and arguments that get passed along with the event. The events then “bubble” upward through the DOM, firing first for a child and then for the parent of that child until it reaches the top element. The advantage of this is that if one wants to know, for example, if the screen has been clicked, a listener doesn’t have to listen at the lowest leaf element of each branch of the DOM; it can simply listen at the top element and wait for the “click” event to “bubble” upwards through the tree. After my aforementioned issue I initially thought that I was missing events because my structure was flawed, so I ended up re-using the above class to implement event bubbling by doing the following:

The example here is the object from which all of my moving game objects (blocks, polyominoes, the game grid, etc) derive from. It defines a single EventDispatcher, through which Event objects are passed. It listens to its own event and when it hears something, it activates its parent’s event, passing through the same object that it received. The advantage here is that by listening to just one “top” object, all of the events that occurred for the child objects are passed to whatever handler is attached to the top object’s dispatcher. In my specific implementation I had each block send an Event up the pipeline when the were moved, each polyomino send an Event when it was moved or rotated, and the game send an Event when the score, level, or line count was changed. By having my renderer listen to just the game object’s EventDispatcher I was able to intercept all of these events at one location.

The disadvantage with this particular method is that each movement has a potentially high computational cost. All of my events are synchronous since Python doesn’t do true multithreading and I didn’t need a high performance implementation. It’s just method calls, but there is a potential for a stack overflow if either a chain of parents has a loop somewhere or if I simply have too tall of an object tree. If I attach too many listeners to a single EventDispatcher, it will also slow things down.

Another problem I have here has to do with memory leaks which I believe I have (I haven’t tested it and this is entirely in my head, thinking about the issues). Since I am asking the EventDispatcher to add a handler which is a bound method to the object which owns it, there is a loop there. In the event that I forget all references to the EventedObject, the reference count will never decrease to 0 since the EventDispatcher inside the EventedObject still holds a reference to that same EventedObject inside the bound method. I would think that this could cause garbage collection to never happen. Of course, they could make the garbage collector really smart and notice that the dependency tree here is a nice orphan tree detached from the rest and can all be collected. However, if it is a dumb garbage collector, it will probably keep it around. This isn’t a new issue for me: I ran into it with doing something like this on one of my C# projects. However, the way I solved it there was to implement the IDisposable interface and upon disposal, unsubscribe from all events that created a circular dependency. The problem there was worse because there wasn’t a direct exclusive link between the two objects like there is with this one (here one is a property of the other (strong link) and the other only references a bound method to its partner (weak…kinda…link)).

Overall, even though there are those disadvantages, I feel that the advantage gained by having all the events in one place is worth it. In the future I will create “filters” that can be attached to handlers as they are subscribed to avoid calling the handlers for events that don’t match their filter. This is similar to Javascript in that handlers can be used to catch one specific type of event. However, mine differs in that in the spirit of Python duck typing, I decided to make no distinction between types of events outside of a string name that identifies what it is. Since I only had one EventDispatcher per object, it makes sense to only have one type of event that will be fed to its listeners. The individual events can then just be differentiated by a property value. While this feels flaky to me since I usually feel most comfortable with strong typing systems, it seems to be closer to what Python is trying to do.

Conclusion

I eventually will put up this Tetris implementation as a gist or repository on github (probably just a gist unless it gets huge…which it could). So far I have learned a great deal about game design and structure, so this should get interesting as I explore other things like networking and such.

Database Abstraction in Python

As I was recently working on trying out the Flask web framework for Python, I ended up wanting to access my MySQL database. Recently at work I have been using entity framework and I have gotten quite used to having a good database abstraction that allows programmatic creation of SQL. While such frameworks exist in Python, I thought it would interesting to try writing one. This is one great example of getting carried away with a seemingly simple task.

I aimed for these things:

  • Tables should be represented as objects which each instance of the object representing a row
  • These objects should be able to generate their own insert, select, and update queries
  • Querying the database should be accomplished by logical predicates, not by strings
  • Update queries should be optimized to only update those fields which have changed
  • The database objects should have support for “immutable” fields that are generated by the database

I also wanted to be able to do relations between tables with foreign keys, but I have decided to stop for now on that. I have a structure outlined, but it isn’t necessary enough at this point since all I wanted was a database abstraction for my simple Flask project. I will probably implement it later.

This can be found as a gist here: https://gist.github.com/kcuzner/5246020

Example

Before going into the code, here is an example of what this abstraction can do as it stands. It directly uses the DbObject and DbQuery-inheriting objects which are shown further down in this post.

This example first loads a user using a DbSelectQuery. The user is then modified and the DbObject-level function save() is used to save it. Next, a new user is created and saved using the same function. After saving, the primary key will have been populated and will be printed.

Change Tracking Columns

I started out with columns. I needed columns that track changes and have a mapping to an SQL column name. I came up with the following:

The Column class describes the column and is implemented as a descriptor. Each ColumnSet instance contains multiple columns and holds ColumnInstance objects which hold the individual column per-object properties, such as the value and whether it has been mutated or not. Each column type has a validation function to help screen invalid data from the columns. When a ColumnSet is initiated, it scans itself for columns and at that moment creates its ColumnInstances.

Generation of SQL using logical predicates

The next thing I had to create was the database querying structure. I decided that rather than actually using the ColumnInstance or Column objects, I would use a go-between object that can be assigned a “prefix”. A common thing to do in SQL queries is to rename the tables in the query so that you can reference the same table multiple times or use different tables with the same column names. So, for example if I had a table called posts and I also had a table called users and they both shared a column called ‘last_update’, I could assign a prefix ‘p’ to the post columns and a prefix ‘u’ to the user columns so that the final column name would be ‘p.last_update’ and ‘u.last_update’ for posts and users respectively.

Another thing I wanted to do was avoid the usage of SQL in constructing my queries. This is similar to the way that LINQ works for C#: A predicate is specified and later translated into an SQL query or a series of operations in memory depending on what is going on. So, in Python one of my queries looks like so:

This would print out a tuple (" WHERE x.column_1 = %s AND x.column_2 > %s", ["4", 5]). So, how does this work? I used operator overloading to create DbQueryExpression objects. The code is like so:

The __str__ function and arguments property return recursively generated expressions using the column prefixes (in the case of __str__) and the arguments (in the case of arguments). As can be seen, this supports parameterization of queries. To be honest, this part was the most fun since I was surprised it was so easy to make predicate expressions using a minimum of classes. One thing that I didn’t like, however, was the fact that the boolean and/or operators cannot be overloaded. For that reason I had to use the bitwise operators, so the expressions aren’t entirely correct when being read.

This DbQueryExpression is fed into my DbQuery object which actually does the translation to SQL. In the example above, we saw that I just passed a logical argument into my where function. This actually was a DbQueryExpression since my overloaded operators create DbQueryExpression objects when they are compared. The DbColumnSet object is an dynamically generated object containing the go-between column objects which is created from a DbObject. We will discuss the DbObject a little further down

The DbQuery objects are implemented as follows:

Each of the SELECT, INSERT, UPDATE, and DELETE query types inherits from a base DbQuery which does execution and such. I decided to make the DbQuery object take a PEP 249-style cursor object and execute the query itself. My hope is that this will make this a little more portable since, to my knowledge, I didn’t make the queries have any MySQL-specific constructions.

The different query types each implement a variety of statements corresponding to different parts of an SQL query: where(), limit(), orderby(), select(), from_table(), etc. These each take in either a DbQueryColumn (such as is the case with where(), orderby(), select(), etc) or a string to be appended to the query, such as is the case with limit(). I could easily have made limit take in two integers as well, but I was kind of rushing through because I wanted to see if this would even work. The query is built by creating the query object for the basic query type that is desired and then calling its member functions to add things on to the query.

Executing the queries can cause a callback “filter” function to be called which takes in the query and the cursor as arguments. I use this function to create new objects from the data or to update an object. It could probably be used for more clever things as well, but those two cases were my original intent in creating it. If no filter is specified, then the cursor is returned.

Table and row objects

At the highest level of this hierarchy is the DbObject. The DbObject definition actually represents a table in the database with a name and a single primary key column. Each instance represents a row. DbObjects also implement the methods for selecting records of their type and also updating themselves when they are changed. They inherit change tracking from the ColumnSet and use DbQueries to accomplish their querying goals. The code is as follows:
